Operating Conditions
Submersible depth 5m.
Liquid temperature up to +40℃.
Ambient temperature up to +40°C.
Max. working pressure: 6bar.
Passage of suspended solid up to 35mm.
Motor
2 pole induction motor.
Insulation: Class B.
Protection: IP X8.
Single-phase with capacitor and thermal overload protection.
Material
Pump body: Stainless steel.
Motor bracket: Stainless steel.
Impeller: Cast iron/Stainless steel.
Motor shaft:Ss420.
Mechanical seal: Ceramic-Graphite, Silicon Carbide-Carbide alloy.
Copper winding.
100% Sufficient Capacity
Long cycle life as nominal
Good quality materials & assembling
