Operating Conditions
Suction lift up to 8m.
Liquid temperature up to +70℃.
Ambient temperature up to +40℃.
Max. working pressure: 6 bar.
Motor
2-pole induction motor:50Hz.
Insulation Class: B.
Protection: IP 44.
With capacitor and thermal overload protection.
Material
Pump body: Cast iron.
Motor bracket: Aluminum.
Impeller: Brass.
ABS(Copper)
Shaft with rotor: Stainless steel or Cs45#.
Mechanical seal: Graphite to ceramic.
Copper winding.
100% Sufficient Capacity
Long cycle life as nominal
Good quality materials & assembling
