Material
Pump Body: cast iron
Motor housing: aluminum
Impeller: brass
Shaft with rotor: 45#steel or stainless steel shaft
Mechanical seal: Graphite to ceramic.
Bearing: C&U or local bearing
Operating Conditions
Liquid temperature up to 40℃
Ambient temperature up to 40℃
Total suction lift up to 8m
Motor
Two-pole induction motor(n=2850 r.p.m)
Insulation Class:B
Protection: Ip44
Continuous service S1
Thermal protector
Single-phase 220V/50Hz, 60Hz if requested
100% Sufficient Capacity
Long cycle life as nominal
Good quality materials & assembling
