Operating Conditions
Suction lift up to 7m.
Liquid temperature up to +40℃.
Ambient temperature up to +40℃.
Max. working pressure: 6 bar.
Motor
2-pole induction motor: 50Hz.
Insulation Class: B.
Protection: IP 44.
Single-phase with capacitor and thermal protector.
Material
Pump body: stainless steel.
Motor bracket: Aluminum.
Impeller: Brass.
Shaft with rotor: Stainless steel or Cs45#.
Mechanical seal: Graphite to ceramic.
Copper winding.
100% Sufficient Capacity
Long cycle life as nominal
Good quality materials & assembling
